BYT1系列隔爆型电力液压推动器  BYT1 SERIES EXPLOSION PROTECTED ELECTRO-HYDRAULIC THRUSTERS

应用 Application

·BYT1系列隔爆型电力液压推动器是一种集电机、离心泵、油缸为一体，机构紧凑的驱动装动控制装置，广泛用于各种鼓式制动器和盘式制动器的驱动装置。

·BYT1 series explosion-proof electric hydraulic thruster is a compact driving and mounting control deviceintegrating motor , centrifugal pump and oil cylinder. ltis widely used in the driving devices of various drum brakes and disc brakes.

符合标准 Standards Compliant

·其隔爆型性能符合GB3836.1-2010《爆炸性环境第 一部分:设备通用要求》、GB3836.2-2010《爆炸性环境第二部分:由隔爆外壳“D”保护的设备》的规定，防爆标志为:Exdl。

·Its flameproof performance complies with GB3836.1-2010 explosive atmospheres part 1:General

requirements for equipment and GB3836.2-2010 explosive atmospheres part 2: equipment protected byflameproofenclosure "D".The explosion-proof mark is Exdl.

使用条件 Operating Condition

·环境温度:-20℃ ~+40℃

·安装地点湿月的月平均较大相对温度不超过90%

·海拔高度不超过1000m

·周围环境的污染等级允许为3级

·电源为三相交流:380V/660v、660V/1140V、50Hz (60Hz)

·有特殊要求时，在订货时协商确定。

OPERATING CONDITION

·Ambient temperature: -20℃~+40℃

·The monthly average maximum relative temperature of the wettest month in the installation site shall not exceed 90%.

·The altitude shall not exceed 1000m

·The pollution level of the surrounding environment is allowed to be level 3.

·Voltages:AC 3 phase,380V/66oV,660V/1140V,50Hz ( 60Hz ) .

·Special requirements can be discussed before production.
