YW系列电力液压鼓式制动器 YW SERIES ELECTRO-HYDRAULIC DRUM BRAKES

应用 Application

·YW系列电力液压鼓式制动器，广泛用于起重、运输、冶金、矿山、港口、码头、建筑机械等机械驱动装置的减速和停车制动。

·YW series electric hydraulic drum brake is widely used for deceleration and parking brake of mechanical driving devices such as lifting, transportation, metallurgy, mine, port, wharf, constructionmachinery and so on.

符合标准Standards Compliant

·YW系列制动器的安装尺寸和制动力矩参数符合DIN15435和JB/T7021-2006标准。技术要求符合JB/T6406-2006标准。

·The installation dimensions and braking torque parameters of YW series brakes conform to DIN15435and JB/T7021-2006 standards.The technical requirements conform to JB/T6406-2006 standard.

使用条件 Operating Condition

·环境温度:-20℃~+50℃

·周围工作环境中不得有易燃、易爆及腐蚀性气体，否则应采用防腐型产品

·相对湿度:空气相对湿度不大于90%

·使用地点的海拔高度符合GB755-2019

·有特殊要求时，在订货时协商确定。

OPERATING CONDITION

·Ambient temperature: -20℃-+50℃

·Flammable, explosive and corrosive gases are not allowed in the surrounding workingenvironment, otherwise anti-corrosion products should be used.

·Relative humidity: therelative humidity of the air is not more than 90%

·The altitude of the place of use conforms to GB755-2019

·Special requirements can be discussed before production.

安装型式 Installation Type

·制动衬垫的安装型式有两种:铆接式和插入式（订货时请说明)。

There are two types of brake pad installation: riveting type and plug-in.type(please specify when ordering).
