YW-L系列电力液压鼓式制动器 YW-L SERIES ELECTRO-HYDRAULIC DRUM BRAKES

应用Application

·YW-L系列电力液压鼓式制动器，广泛用于起重、运输、冶金、矿山、港口、码头、建筑机械等机械驱动装置的减速和停车制动。

APPLICATION

·YW-L series electric hydraulic drum brake is widely used for deceleration and parking brake of mechanical driving devices such as lifting, transportation, metallturgy, mine, port, wharf, constructionmachinery and so on.

主要特点MainFeature

·主要摆动铵点均设有自润滑轴承，传动效率高，寿命长，使用过程中无需润滑。

·性能安全可靠，制动平稳，动作频率高。

·制动力矩直接显示。

·无石棉制动衬垫与制动瓦块采用卡装插入式。安全可靠，更换方便、快捷。

MAIN FEATURE

·Main hinge points are equipped with self-lubricating bearing,making high efficiency of transmission,)long ser vice life.Lubricating is unnecessary during operation.

·Safe and reliable performance,smooth braking, high action frequency.

·The braking torque is displayed directly.

·The nonasbestos brake pad and the brake pad adopt the clamping plug-in type. lt is safe and reliable,convenient and quick to replace.

使用条件 Operating Condition

·环境温度:-20℃ ~+50℃

·制动器周围工作环境中不得有易燃、易爆及腐蚀性气体，否则应采用防腐型产品。

·相对湿度:空气相对湿度不大于90%

·使用地点的海拔高度符合GB755-2019

OPERATING CONDITION

·Ambient temperature: -20℃~+50℃

·There shall be no inflammable or explosive gas in the surrounding working environment.

·Relative humidity: the relative humidity of the air is not more than 90%

·The altitude of the place ofuse conforms to GB755-2019

符合标准 Standards Compliant

·YW-L系列制动器的安装尺寸符合DIN15435和JB/T7021-2006标准。技术要求符合JB/T6406-2006标准。

STANDARDS COMPLIANT

·The installation dimension of YW-L brake conforms to DIN15435 and JjB/T7021-2006standards.The technical requirements conform to JB/T6406-2006 standard.
