MW(Z)系列电磁铁鼓式制动器  MW(Z) SERIES ELECTROMAGNETIC DRUM BRAKES

应用Application

·MW(Z)系列电磁铁鼓式制动器，广泛用于起重、运输、冶金、矿山、港口、码头、建筑机械等机械驱动装置的减速和停车制动。

APPLICATION

·MW(Z)series electromagnetic drum brakes are widely used for deceleration and parking brakes of mechanical drive devices such as lifting, transportation, metallurgy , mines, ports, docks and constructionmachinery.

符合标准Standards Compliant

·该系列制动器的安装尺寸和制动力矩参数及技术要求符合JB/T7685-2006标准。

·Installation dimensions, braking torque parameters and technical requirements of this series of brakesconform to JB/T7685-2006 standard.

使用条件 Operating Condition

·环境温度:-25℃~+40℃

·交流380V、50Hz电源，MWZ产品为直流电源，额定电压为220V。

·制动器周围工作环境中不得有易燃、易爆及足以腐蚀金属及破坏绝缘的气体和导电尘埃。

·相对湿度:空气相对湿度不大于90%·使用地点的海拔高度不超过2000m

·户外雨雪侵蚀或有腐蚀性气体和介质应采用防腐型产品。

·有特殊要求时，在订货时协商确定。

OPERATING CONDITION

·Ambient temperature: -25℃~+40℃

·AC 380V 50Hz,The MWZ product is a DC power supply, with a rated voltage of 220v.

·The working environment around the brake must be free from inflammable, explosivegases and conductive dust sufficient to corrode metals and destroy insulation.

·Relative humidity: the relative humidity of the air is not more than 90%

·The altitude of the place of use shall not exceed 2000m

·Rain and snow erosion or corrosive gases and media should be corrosionresistant.

·Specialrequirements can be discussed before production.
